This kit provides two mounting brackets. The angled bracket is intended to mount the desktop reader perpendicular to a flat surface in a horizontal or vertical orientation. The angle of the bracket can be slightly adjusted if necessary.
The flat bracket is intended to mount the desktop reader against a flat surface.
Both brackets are secured to the reader using the provided screws.
The bracket is then mounted to a flat surface using the provided foam tape. You may optionally use your own bolts or screws to secure the brackets to your equipment. The mounting holes are sized to work with #4 screws (4-5mm Diameter)
This Mounting Bracket is compatible with any product that comes in the Desktop Reader housing, such as:
The kit is available in black (SKU: KT-SHBKT) or pearl (SKU: KT-SHBKT-G).
The kit (SKU: KT-SHBKT or KT-SHBKT-G) includes:
- (1) Angle Bracket
- (1) Flat Bracket
- (2) #4 Screws
- (2) Foam Tape Squares
- (1) Mounting Instruction Sheet
The below kits are identical to KT-SHBKT except they come with only the angle bracket
(SKU: KT-ANGLE) or the flat bracket (SKU: KT-FLAT).
The kit (SKU: KT-ANGLE) includes:
- (1) Angle Bracket (Black)
- (2) #4 Screws
- (2) Foam Tape Squares
- (1) Mounting Instruction Sheet
The kit (SKU: KT-FLAT) includes:
- (1) Flat Bracket (Black)
- (2) #4 Screws
- (2) Foam Tape Squares
- (1) Mounting Instruction Sheet
